Gantry CNC Plasma steel plate cutting machine
Equipment Overview:
CNC flame/plasma cutting machine include CNC system,drive system,electric-gas system,gas system and mechanical system.this machine mainly used for the steel plate cutting by flame or plasma,Complete function,high automatic,Advanced configuration,high cutting precise,good quality, Steady dynamic.CNC system and server system adapt good functional product,convenient operating screen,easy operate.
Product Description
|
Item |
Technical parameters |
|
gauge |
200-10000mm |
|
Rail length |
≥4000mm |
|
Effective longitudinal range |
≤ 3200mm |
|
Effective vertical range |
≤ 2000mm |
|
Cutting torch’s number |
2 |
|
Unload travel speed |
10000mm/min |
|
Plasma cutting speed |
Depend on the plasma power |
|
Cutting torch lift distance |
4000mm |
|
Flame cutting steel plate thickness |
20-100mm |
|
Flame cutting speed |
20-1000mm/min |
|
Note:we deign the technical parameters according to the workpiece plan of customer,and then produce the products. |
|
